ITEM |
UNIT |
Model |
IROTH-10-18 |
IROTH-20-24 |
IROTH-30-36 |
IROTH-40-45 |
IROTH-50-60 |
IROTH-75-75 |
IROTH-75-80 |
IROTH-100-90 |
Temp control range |
℃ |
+25℃-400℃Inlet water temperature +25℃-400℃ |
Tempcontrol accuracy |
℃ |
PID±1℃ |
Power supply |
/ |
3P AC380V/480V 50HZ(3phase+Earth) |
Heat transfer medium |
/ |
Thermo conductive oil |
Cooling method |
/ |
Indirect cooling |
Without Cooling |
Expansion tank |
L |
67 |
67 |
67 |
100 |
100 |
100 |
150
(External) |
150
(External) |
Heating capacity |
KW |
15/18 |
18/24 |
30/36 |
40/45 |
50/60 |
75 |
80(40+40)/90(45+45) |
96(48+48) |
Pump power |
KW |
1.5 |
1.5 |
2.2 |
2.2 |
3.0 |
4.0 |
4.0 |
5.5 |
Pump flow |
m³/h |
6 |
6 |
10 |
12.5 |
16 |
12.5/18 |
12.5/18 |
30/34 |
Pump head |
m |
28 |
28 |
28 |
30 |
32 |
50/38 |
50/38 |
50/40 |
Max.power consumption |
KW |
19.5 |
25.5 |
38.5 |
48 |
63 |
79 |
94 |
102 |
Alarm function |
/ |
Pump reversal/Oil shortage/Overheating/Overload/Abnormal heating |
|
Cooling water pipe |
inch |
1/2″ |
1/2″ |
1/2″ |
1/2″ |
1/2″ |
1/2″ |
NA |
NA |
Circulating oil pipe |
inch |
1″ |
1″ |
1″ |
1-1/4″ |
1-1/4″ |
1-1/2″ |
1-1/2″ |
2″ |
Size(L×W×H) |
mm |
2100*600*1350 |
2100*600*1350 |
2250*700*1550 |
2250*800*1650 |
2450*800*1650 |
2450*800*1650 |
2300*800*1800 |
2300*800*1800 |
The specifications above are subject to changes without notice ,some specifications may be customized.
