ITEM |
UNIT
| IRDOT-15-D | IRDOTC-12-D | IROT-20-D | IROTC-15-D | IROTC-30-D | IROTC-24-D | IROT-40-D | IROTC-30-D |
Temp control range | ℃ | Inlet water temperature +45℃~320℃ |
Temp control accuracy | ℃ | PID ±1 |
Power supply | | AC 3N-380V/400V-50HZ（3 phase+Earth） |
Heat transfer medium | | Thermo conductive oil |
Cooling method | | Indirect Cooling |
Cooling capacity | ㎡ | 3/8 | 3/8 | 1/2 | 1/2 | 0.36+0.36 | 0.48+0.48 | 0.48+0.48 | 0.48+0.48 |
Expansion tank | L | 40 | 40 | 67 | 67 | 62 | 62 | 62 | 62 |
Heating capacity | KW | 15*2 | 12*2 | 20*2 | 15*2 | 30+30 | 24+24 | 40+40 | 30+30 |
Moter power | KW | 1 1/9 | 1 1/9 | 3 | 3 | 1.1+1.1 | 3+3 | 3+3 | 3+3 |
Pump flow | L/min | 30 | 30 | 75 | 75 | 30+30 | 75+75 | 75+75 | 75+75 |
Max. power consumption | KW | 31 | 25 | 43 | 33 | 62 | 54 | 86 | 66 |
Alarm function | | Pump reversal/Oil shortage/Overheating/Overload/Abnormal heating |
Cooling water pipe | inch | 1/2 | 1/2 | 3/4*2 | 3/4*2 |
Circulating oil pipe | inch | 3/4 | 1 | 3/4*2 | 1*2 |
Size(L×W×H) | mm | 1400*500*1150 | 1650*550*1250 | 1380*600*1400 | 1380*600*1400 |
Remark :Cooling water 20 l/min (30℃·1kg/c㎡) media flow 50 ~ 100 l/min. |
The above specifications are subject to changes without notice,some specifications may be customized.
