IRC- |
075RTW |
125RTW |
150RTW |
200RTW |
250RTW |
300RTW |
350RTW |
400RTW |
500RTW |
600RTW |
700RTW |
||
Medium |
Fresh water |
||||||||||||
Cooling capacity |
kcal/h |
221932 |
380120 |
451672 |
653720 |
770078 |
925446 |
1063734 |
1307441 |
1540157 |
1850892 |
2127468 |
|
kW |
258 |
442 |
525 |
760 |
895 |
1076 |
1237 |
1520 |
1791 |
2173 |
2474 |
||
Power input |
kW |
45 |
76 |
90 |
123 |
144 |
175 |
200 |
245 |
289 |
350 |
399 |
|
COP |
W/W |
5.8 |
5.8 |
5.8 |
6.2 |
6.2 |
6.2 |
6.2 |
6.2 |
6.2 |
6.2 |
6.2 |
|
Running current |
A |
89 |
152 |
181 |
245 |
289 |
350 |
399 |
490 |
578 |
699 |
798 |
|
Refrigerant |
R134a |
||||||||||||
Steps control |
% |
30~100,Variable frequency |
|||||||||||
Temperature control range |
℃ |
+7~+25 |
|||||||||||
Control type |
Automatic control, Color LCD touch screen |
||||||||||||
Power supply type |
3N,380V,50Hz |
||||||||||||
Safety protection device |
Overload、 Inverse phase、High/Low pressure、 Safety valve、 Water flow、Exhaust temperature alarm、 Antifreeze protection、Surge protection |
||||||||||||
Compressor |
Type |
Air suspension oil-free centrifugal |
|||||||||||
Start type |
VFD startup |
||||||||||||
Amount |
Sets |
1 |
2 |
||||||||||
Condenser |
Type |
Shell and tube |
|||||||||||
Water flow |
m3/h |
52 |
89 |
106 |
152 |
179 |
215 |
247 |
304 |
358 |
434 |
494 |
|
Water pressure drop |
kPa |
25 |
30 |
35 |
40 |
45 |
50 |
55 |
60 |
70 |
80 |
90 |
|
In/Out pipe size |
DN |
100 |
100 |
125 |
125 |
150 |
200 |
200 |
200 |
200 |
250 |
250 |
|
Evaporator |
Type |
Spray shell and tube |
|||||||||||
Water flow |
m3/h |
44 |
76 |
90 |
131 |
154 |
185 |
213 |
261 |
308 |
374 |
425 |
|
Water pressure drop |
kPa |
25 |
28 |
32 |
38 |
40 |
45 |
52 |
55 |
68 |
78 |
85 |
|
In/Out pipe size |
DN |
100 |
100 |
125 |
125 |
150 |
200 |
200 |
200 |
200 |
250 |
250 |
|
L×W×H |
mm |
3100×1300×2000 |
3100×1300×2000 |
3400×1600×2200 |
3600×1600×2200 |
3600×1600×2300 |
3800×1600×2300 |
3800×1600×2400 |
3900×2200×2400 |
3900×2200×2400 |
3900×2300×2450 |
3900×2300×2450 |
|
Net weight |
kg |
2200 |
2700 |
4300 |
3900 |
4500 |
5500 |
6500 |
7500 |
8500 |
9500 |
10500 |
|
Refrigerant charge |
kg |
110 |
150 |
180 |
200 |
230 |
280 |
330 |
400 |
460 |
560 |
660 |
|
Remarks:The above parameters based on chilled water inlet/outlet temperature of 12℃/7℃, cooling water inlet/outlet temperature of 30℃/35℃.
